CSR Synergy 藍牙WIFI解決方案
名稱：IC集成電路
品牌：
型號：
簡介：CSR Synergy 藍牙WIFI解決方案CSR Synergy provides the fastest path to market for mobile device developers. By providing an inte...
申請服務
- 產(chǎn)品介紹
CSR Synergy 藍牙WIFI解決方案CSR Synergy provides the fastest path to market for mobile device developers. By providing an integrated host software solution for the spectrum of desirable wireless connectivity technologies, CSR Synergy allows you to add feature sets without the usual integration and interoperability problems.
CSR Synergy builds on the success of BCHS – the most widely used embedded Bluetooth software stack in the world today. Like BCHS, CSR Synergy has source code in ANSI C, is easily extendable and has a virtual OS for easy portability. Using CSR Synergy OEMs only have one solution to port, resulting in a smaller memory footprint and less resources required for the porting job than separate solutions. It is also easy to remove or add-in technologies to CSR Synergy.
CSR Synergy 藍牙WIFI解決方案Key features
CSR Synergy offers support for all the technologies in CSR's portfolio in a single, cohesive package:
■Audio-DSP functions
■Bluetooth
■Bluetooth low energy
■GPS
■FM transceiver
■NFC
■UWB
■Wi-Fi
CSR Synergy offers performance improvements in wireless technology interoperability and enables advanced new end-user use-cases.
CSR Synergy 藍牙WIFI解決方案Benefits
An elegant, proven software architecture
CSR Synergy's single modular framework supports the range of wireless connectivity technologies now being used and considered by mobile device developers. This slashes time-to-market, and opens up major new product possibilities:
■Porting is rapid - ONE process handles multiple wireless technologies
■A unified API for all technologies reduces integration time
■Built-in and tested inter-technology communication ensures perfect coexistence
■Multi-technology support allows new use-cases to be created with minimal
■Multi-technology features include built-in support for AMP (Alternate MAC/PHY or Bluetooth v3.0+HS)
■Single software system can be rolled-out for an entire product range
By taking a full system approach, CSR Synergy guarantees that multiple wireless technologies will work together and coexist perfectly. The performance guarantee includes advanced features and use-cases such as advanced Bluetooth/Wi-Fi coexistence, and seamless switching from Bluetooth to Wi-Fi or UWB.
CSR Synergy 藍牙WIFI解決方案Create radical new products
CSR Synergy frees OEMs to concentrate on developing powerful new applications and flexible user interface software, to differentiate their products in competitive markets.
CSR Synergy will enable a variety of innovative next-generation mobile device applications:
■Mobile devices with a choice of wireless connectivity technologies could automatically switch from Bluetooth to Wi-Fi or UWB for instance, and back again, to speed transfer and save battery power when moving large files such as videos or music
■When a mobile device moves out of range of the office WLAN, it might turn GPS on for the car-ride home, and vice-versa
■Use CSR Synergy’s innovative Proximity Pairing feature that allows the end-user to easily find the correct Bletooth Device, connect and perform appropriate action
■Turn the mobile device into a portable Wi-Fi accesspoint using CSR Synergy’s Wi-Fi Direct feature
Product details
CSR Synergy supports:
■Fully qualified as Blueotooth v2.1+EDR, v3.0+HS and v4.0 low energy
■29 Bluetooth Profiles including MAP and HDP
■Proximity Pairing for easier pairing of devices
■Wi-Fi b/g/n including WAPI and WPS
■Wi-Fi Direct
■High level software coexistence between Wi-Fi and Bluetooth to enable world leading performance
■FM Rx/Tx with RDS
■InfoStream (protocol packaging information alongside streamed audio such as caller name or headset battery level)
■Amplifi (switches seamlessly from Bluetooth to Wi-Fi or UWB to speed file transfer)
■Full BSPs included for Nucleus, Windows and Linux
